รายละเอียดสินค้า

Created with Pixso. บ้าน Created with Pixso. ผลิตภัณฑ์ Created with Pixso.
โมเนลอัลลอยด์
Created with Pixso.

High Strength Monel K500 Tube Corrosion Resistant Nickel Alloy Pipe

High Strength Monel K500 Tube Corrosion Resistant Nickel Alloy Pipe

ชื่อแบรนด์: DLX
หมายเลขรุ่น: โมเนล K500
ขั้นต่ำ: 5
เงื่อนไขการชำระเงิน: แอล/C, T/T, เวสเทิร์นยูเนี่ยน
ความสามารถในการจัดหา: 500 ตันต่อเดือน
ข้อมูลรายละเอียด
สถานที่กำเนิด:
China Jiangsu
ได้รับการรับรอง:
CE,ROHS
วัสดุ:
ทองแดงนิเกิล
นิกเกิล (นาที):
63%
อุณหภูมิคูรี:
21-49 ℃
ความหนาแน่น:
8.05g/cm3
แอปพลิเคชัน:
ป้องกันการกัดกร่อน
เงื่อนไข:
แข็ง/อ่อน
พื้นผิว:
สดใส, ออกไซด์
เวลาการส่งมอบ:
7-50 วัน
จุดหลอมเหลว:
1288-1343 ℃
ชื่อ:
โมเนล K500 ท่อ
รายละเอียดการบรรจุ:
แพ็คเกจ Spool พร้อมกล่องกระดาษ, แพ็คเกจม้วนพร้อม polybag
สามารถในการผลิต:
500 ตันต่อเดือน
เน้น:

Corrosion Resistant Monel K500 Pipe

,

Monel K500 Nickel Alloy Pipe

,

Nickel Alloy Monel K500 Tube

รายละเอียดสินค้า

High Strength Monel K500 Tube Corrosion Resistant Nickel Alloy Pipe 0

Monel K500 tube Corrosion Resistant Alloys nickel alloy pipe

What material is monelk500?

   Monel K500 is a high-strength, corrosion-resistant nickel copper alloy material. It is composed of about 65% nickel and about 30% copper, while containing small amounts of elements such as aluminum, iron, carbon, manganese, and titanium. The Monel K500 has excellent corrosion resistance, especially in corrosive media such as seawater, sulfuric acid, and hydrochloric acid. In addition, the Monel K500 also has good wear resistance, high temperature resistance, and fatigue resistance, making it widely used in marine engineering, chemical equipment, aerospace and other fields.

High Strength Monel K500 Tube Corrosion Resistant Nickel Alloy Pipe 1




  • Chemical Properties of Monel K500

Ni Cu Al Ti C Mn Fe S Si

63

Max

27-33 2.3-3.15 0.35-0.85 0.25 max 1.5 max 2.0 max 0.01 max 0.50 max


  • Application

. Sour-gas service applications
. Oil and gas production safety lifts and valves
. Oil-well tools and instruments like drill collars
. Oil well industry
. Doctor blades and scrapers
. Chains, cables, springs, valve trim, fasteners for marine service
. Pump shafts and impellers in marine service




  • ,Mechanical Properties

    Typical Room Temperature Tensile Properties of Annealed Material

    Product Form Condition Tensile (ksi) .2% Yield (ksi) Elongation % Hardness
    Rod & Bar Hot-Finished/Aged 140-190 100-150 30-20 27-38 HRC
    Rod & Bar Hot Finished/Annealed 90-110 40-60 45-25 75-90 HRB
    Rod & Bar Hot Finished/Annealed/Aged 130-165 85-120 35-20 24-35 HRC
    Rod & Bar Cold-Drawn/Aged 135-185 95-160 30-15 25-41 HRC
    Rod & Bar Cold-Drawn/Annealed/Aged 130-190 85-120 30-20 24-35 HRC
    Plate ot-Finished/Aged 140-180 100-135 30-20 27-37 HRC
    Sheet Cold-Rolled/Annealed 90-105 40-65 45-25 85 HRB Max
